Description
7Semi ICM-20948 9DoF IMU Breakout Board (MPU-9250 Upgrade)
The 7Semi ICM-20948 9DoF IMU Breakout is a compact and versatile motion tracking module designed for applications in smartphones, wearables, and IoT devices. It integrates a 3-axis gyroscope, 3-axis accelerometer, and 3-axis magnetometer, providing comprehensive 9-axis orientation and motion sensing.
The breakout board features a Digital Motion Processor (DMP) to offload computations, supports both I²C and SPI interfaces, and operates within a supply voltage range of 1.95V to 3.6V. This makes it an ideal choice for projects requiring precise and efficient motion tracking capabilities.
Features:
-
Digital Motion Processor (DMP): Offloads sensor fusion computations, enhancing performance and reducing host processor load.
-
Flexible Communication Interfaces: Supports both I²C and SPI interfaces for versatile integration with microcontrollers and processors.
-
Wide Supply Voltage Range: Operates between 1.95V and 3.6V, accommodating various power requirements.
- Compact Form Factor: Ideal for space-constrained applications in portable and wearable devices.
Package Includes:
- 1 x 7Semi ICM-20948 9DoF IMU Breakout Board
Specifications:
| Specification | Details |
|---|---|
| Sensor Type | 9DoF (Gyroscope, Accelerometer, Magnetometer) |
| Digital Motion Processor (DMP) | Yes |
| Communication Interfaces | I²C, SPI |
| Operating Voltage | 1.95V to 3.6V |
| Dimensions (LxWxH) | 2 x 1.7 x 2 cm |
| Weight | 4 gm |
| Mounting | Through-hole pins |
